ZDSC Silicon Carbide Slurry Pump

ZDSC Silicon Carbide Slurry Pump

WeChat
Sina Weibo
QQ
QQ space
Douban
Baidu Post Bar
The main technical parameters
Diameter:40~300 mm
Flow:10~3000 m3/h
Head: 10~95 m
Temperature: -10~+150℃

Application Range
Suitable for environments with a pH of 1–14, without restrictions on chloride ion or fluoride ion concentrations in slurries.The diameter of medium particles must be less than 5 mm.The temperature of the medium should range from -40°C to 150°C.NPT silicon carbide ceramic cast pumps and pipelines exhibit extremely high hardness, exceptional resistance to chemical corrosion, and oxidation .
0086-813-8269991
Features and StructureProduct materialsProduct ConfigurationType spectrogramProduct Site Map



Product Characteristics

  • High Hardness: Mohs hardness rating of 7–8 .

  • Exceptional Chemical Corrosion Resistance:

  • Resistant to chloride ion concentrations up to 800,000 ppm.

  • Resistant to fluoride ion concentrations up to 200,000 ppm .

  • High-Temperature Resistance: Can withstand medium temperatures up to 150°C .

  • Lightweight: The density of NPT silicon carbide ceramic cast components is 2.4–2.6 g/cm3, only about one-third the density of typical steel materials (7.8–8.0 g/cm3) used in the market .

  • Smooth Product Surface:

  • The flow channels of NPT silicon carbide ceramic cast impellers and pump casings are smooth, reducing frictional resistance and minimizing mechanical wear on components, thereby extending service life .

  • NPT silicon carbide ceramic cast pump components have a service life 2–3 times longer than that of metal materials .

Product Structure

1-Pump shaft 2-Rear bearing3-Bracket 4-Front bearing 5-Shaft seal
6-Intermediate frame7-Rear guard plate8-Pump body 9-Impeller10-Front guard plate


Casing

Silicon Carbide

Impeller

Silicon Carbide

Front guard plate

Silicon Carbide

Rear guard plate

Silicon Carbide

Intermediate frame

HT

Bracket

HT

Shaft

40Cr


Main Configuration

Manufacturer standard

Optional Configuration

Motor

Chinese Brand（Chonqing/Xi’An

Nanyang, Jiamusi, ABB, Innomotics or designated brands

Bearing

Havalo

SKF，NSK，FAG or designated brands

Mechanical Seal

Zigong

Chengdu Yitong,Sinoseal

Flange and matching flange

Industry Standards

European standard, German standard, American standard, Japanese standard, national standard

Coupling

Pin Coupling
